Bitumen emulsion CSS-1h is a mixture of bitumen droplets in the water phase with the help of a cationic emulsifier dissolved in water. It is a slow setting, as a result, it takes time for CSS-1h to dry after it is applied to a surface.
There is nearly 60% bitumen in CSS-1h with a high penetration value and the rest is water phase. It is made based on ASTM D 2397 M-13. The HS code of this product is 27150090.
Continue reading if you want to learn more about bitumen emulsion CSS-1h.
Bitumen Emulsion CSS-1h Latest Price
| Bitumen Emulsion CSS-1h Price (Reconditioned Drum) | |
|---|---|
| Port | Price |
| FOB Middle East | 571 ± 5$ |
February 10, 2025 | |
Check out other Cationic Bitumen Emulsion Prices here.
Bitumen Emulsion CSS-1h Tests
Some specific laboratory tests are conducted to recognize CSS-1h quality.
Bitumen emulsion tests names and their standard measurement methods are listed below:
- Residue by Evaporation Test (INSO13580)
- Sieve Test (ASTM D6933)
- Saybolt Viscosity Test (ASTM D7496)
- Distillation Test
- Storage Stability Test (ASTM D6930)
- Density Test
The Specification of CSS-1h
The below table shows the CSS-1h specification. CSS1-h is only approved from a quality point of view if each feature falls within a certain range.
| Bitumen Emulsion CSS-1h Specifications | |||
|---|---|---|---|
| Specification | Test Method | Min. | Max. |
| Cement Mixing % | ASTM D6935 | – | 2.0 |
| Storage Stability in 24-H (%) | ASTM D6930 | – | 1 |
| Sieve Test (%) | ASTM D6933 | – | 0.1 |
| Viscosity Saybolt Furel At 50 °C | ASTM D7496 | 20 | 100 |
| Particle Charge (None) | ASTM D7402 | Positive | |
| Distillation | |||
| Residue % | ASTM D6997 | 57 | – |
| Test On Residue From Distillation Test | |||
| Penetration, At 25 °C, 100 gr on 5 sec, (0.1 mm) | ASTM D5 | 40 | 90 |
| Ductility, At 25 °C, 5 cm/min, (cm) | ASTM D113 | 40 | – |
| Solubility in TCE, WT% | ASTM D2042 | 97.5 | – |
International Inspections
The CSS-1h cargo should be subjected to some quality tests before it is delivered to the destination port by the vessel.
These tests are taken by a third party agent of SGS or Geo-Chem international inspections. It is for the customer’s confidence in the purchased goods.
Bitumen Emulsion CSS-1h Packing Type
Bitumen emulsion CSS-1h packing must maintain emulsion stability and prevent leakage.
In addition to preventing the bitumen emulsion from leaking, proper packaging should prevent the bitumen emulsion from being exposed to environmental conditions.
The suitable packings for bitumen emulsion CSS-1h are as below:
- New Steel Drum
- Barrel
- IBC
- Flexi tank
- Reconditioned drums
Our company provides bitumen emulsion CSS-1h in various types of new steel drums based on the needs of the customer.
Bitumen Emulsion CSS-1h Payment Term
Infinity Galaxy provides payment terms just in TT. It is required for the customer to pay the 50% advance and balance against the bill of lading draft. For more information contact our experts.
CSS-1h Applications
One of the most commonly used types of bitumen for road construction is CSS-1h. It is mainly used as prime coat. In asphalt construction, prime coat bonds the binder course to the permeable base course. Thus the asphalt base can be maintained by CSS-1h.
It is designed for use in slurry seals to protect airports and urban roads.
The slow setting property of CSS-1h makes it ideal to cover surfaces in areas with very fine and eroded soil to prevent dust from spreading. It can be used successfully for soil stabilization, tack coats, fog seals, and as a dust suppressant.
CSS-1h is a safe and environmentally friendly alternative to cutbacks. One non-paving use is the mulch treatment of soil that has been seeded and fertilized. This work leads to the prevention of soil erosion and maintains the moisture and richness of the soil.
It can be used to make cold asphalt mixture where hot mix asphalt cannot be used.
Infinity Galaxy, Bitumen Emulsion CSS-1h Supplier
Providing quality products at workable prices has been our mission since 2012.
Infinity Galaxy exports bitumen emulsion, which is crucial to maintaining roads and enabling better transportation.
To place an order or ask questions about CSS-1h bitumen emulsion, you can contact our experts via WhatsApp or the form below.
